CasaFan Eco Airscrew ceiling fan 152 cm black

Zoro Tools

ECO AIRSCREW ceiling fan, rotor blade 1520 mm, grey/matt black. Supplied = flat pack. Product type = ceiling fans. Rotor blade diameter = 1520 mm. Housing colour = matt black. Blade colour = grey. Number of speed settings = 6. Max. speed = 125 rpm. Max. air volume = 11712 m/h. Power = 0.028 kW. Sound pressure LPA (-3 m) = 15 dB (A) Sound power LWA = 34.4 dB (A) Fittings = remote control, wall switch. Protection type = IP00. Height = 360 mm. Width = 1520 mm. Depth = 1520 mm. Mains voltage = 220 - 240 V/~50 Hz. Ceiling-blade spacing = 275 mm. Number of blades = 3 pcs. Number of blades included with delivery = 3 pcs. 3 handmade solid wood blades in classic propeller shape. For rooms from 28 to 40 m, high output of 11712 m/h. 6 speed settings, forwards/reverse rotation (summer and winter mode) selected using remote control. Very energy efficient, service ratio 7.0 (m/min.) /W in accordance with EU Directive 206/2012. Lowest setting guarantee to not cause draughts, also ideal for recirculating heat in winter. Can be installed at angles up to 12. 25-year manufacturer warranty on the motor. An eyecatcher for any room, whether in the office or at home. State-of-the-art, energy saving DC/EC motor. For rooms with a normal height, the distance between the ceiling and blades is 360 mm. Includes remote control with sleep timer, slow motion setting. Supplied with wall bracket and 200 mm ceiling rod. Integration of a lamp not possible. Performance data: Speed setting 1 = 50 rpm/power consumption setting 1 = 4.4 watts/sound power level L W = < 32 dB (A)/sound pressure level L P -3 m = < 15 dB (A) Speed setting 2 = 61 rpm/power consumption setting 2 = 5.9 watts/sound power level L W = < 32 dB (A)/sound pressure level L P -3 m = < 15 dB (A) Speed setting 3 = 81 rpm/power consumption setting 3 = 11 watts/sound power level L W = < 32 dB (A)/sound pressure level L P -3 m = < 15 dB (A) Speed setting 4 = 98 rpm/power consumption setting 4 = 18.7 watts/sound power level L W = < 32.4 dB (A)/sound pressure level L P -3 m = < 15 dB (A) Speed setting 5 = 117 rpm/power consumption setting 5 = 27.3 watts/sound power level L W = < 34.1 dB (A)/sound pressure level L P -3 m = < 15 dB (A) Speed setting 6 = 125 rpm/power consumption setting 6 = 28 watts/sound power level L W = < 34.4 dB (A)/sound pressure level L P -3 m = < 15 dB (A) Air speed 1.5 m above floor = 2.24 m/s. The maximum air speed is specified at the highest setting at a height of 1.5 m above the floor in a room 3 m high. This will help you estimate draughts that will occur at head height when sitting under the ceiling fan. This specification refers to the highest speed. Precise speed levels with as many settings as possible allows pleasant, draught-free operation even in winter by recirculating the warm air that is under the ceiling. Noise measurements were carried out at the VDE Testing and Certification Institute in Offenbach. The lower threshold for the measurement by the laboratory is 32 dB (A) for sound power L W and 15 dB (A) for the sound pressure L P -3 m. Because many ceiling fans on the market feature one or the other value in the specifications, we are providing the measured noise values as both sound power L W and sound pressure L P -3 m.

Lights.co

Wooden ceiling fan Eco Airscrew in propeller look Fans of historical aviation will be thrilled at the sight of the ceiling fan Eco Airscrew. The blades are made of aged wood and their characteristic shape is reminiscent of old propeller airplanes. The ceiling fan, which is particularly suitable for large rooms and always runs quietly, is functionally on the cutting edge. Functions Six speed levels allow a situation-specific selection. The idea of energy efficiency is implemented with the patented DC motor and the reverse function. The latter ensures redistribution of warm air in winter, so heating costs can be reduced. All settings can be controlled via the supplied remote control, for which a wall bracket is included. Technical data - Mounting also on slopes up to 16° - Motor with energy-saving, patented DC technology - Weight: 7 kg Power per speed: - 3.2 W at 49 rpm - 3.6 W at 58 rpm - 4.9 W at 78 rpm - 6.8 W at 94 rpm - 10.4 W at 121 rpm - 16.1 W at 149 rpm

ManoMano

Dimensions and technical details 220-240 V ~ 50 Hz Diameter: 152cm / 60" Housing colour: matt black Blade colour: grey washed Motor wattage: 4.4 / 5.9 / 11 / 18.7 / 27.3 / 28 W Revolutions per minute: 50 / 61 / 81 / 98 / 117 / 125 Max. airflow rate: 195.2 m³/min / 6893 cfm Max. sound pressure level Lp-3m: < 15 dB(A) Max. sound power level: 34.5 dB(A) Ceiling to blades: 27.5cm / 10.8" Ceiling to bottom: 36cm / 14.2" Diameter canopy: 18cm / 7.1" Max. ceiling slope: 12° Forward and reverse function (summer and winter mode) Includes remote control: 6 fan speeds / off, running direction Weight: 7kg / 15.4lbs
