VORTICE 12455 230/9"" AR LL S
Description
ManoMano
Dimensions and technical details 220-240 V ~ 50 Hz Colour: white Material: impact-resistant, UV-resistant ABS plastic Nominal size: 230 mm Speed levels: 1 Wattage: 35 W Current consumption: 0.19 A Revolutions per minute supply air: 1300 Revolutions per minute exhaust air: 1200 Max. airflow rate supply air: 370 m³/h Max. airflow rate exhaust air: 700 m³/h Sound pressure level Lp-3m: 43.6 dB(A) IP rating: IPX4 Protection class: II Max. ambient temperature: +50°C Weight: 3.45 kg Plain bearings Automated internal shutter flap prevents cold air from coming in once the fan is turned off (can be opened manually) Optional CR controllers allow reversing and speed control Model A B C D E min. E max. Ø Cutout 230/9 294 mm 297 mm 31 mm 130 mm 2 mm 38 mm 257-262 mm
Description
(2)
Dimensions and technical details 220-240 V ~ 50 Hz Colour: white Material: impact-resistant, UV-resistant ABS plastic Nominal size: 230 mm Speed levels: 1 Wattage: 35 W Current consumption: 0.19 A Revolutions per minute supply air: 1300 Revolutions per minute exhaust air: 1200 Max. airflow rate supply air: 370 m³/h Max. airflow rate exhaust air: 700 m³/h Sound pressure level Lp-3m: 43.6 dB(A) IP rating: IPX4 Protection class: II Max. ambient temperature: +50°C Weight: 3.45 kg Plain bearings Automated internal shutter flap prevents cold air from coming in once the fan is turned off (can be opened manually) Optional CR controllers allow reversing and speed control Model A B C D E min. E max. Ø Cutout 230/9 294 mm 297 mm 31 mm 130 mm 2 mm 38 mm 257-262 mm
AmazonVario.pdf, Weight: 7.605948039 Pounds, Manufacturer: VORTICE
