Amp 1658651 1 37 po female sub D connector AMPLImitE HDP 20 series

General description The Amp 1658651-1 is a 37-position female sub-D connector from the AMPLImitE HDP-20 series, designed for reliable signal connections in various applications. Technical specifications Connector type: D-Sub Connector type: Socket for female contacts Number of positions: 37 Number of rows: 2 Shell dimensions: 4 (DC, C) Contact type: Signal Mounting type: Free hanging Flange specifications: Housing/Shell (without thread) Armored: Yes Shell material: Steel Envelope finish thickness: 200 µin (5.08 µm) Dielectric material: Polyamide (PA), Nylon, glass reinforced Note: Contacts not included
