DIGITUS Patch Panel Modular For Keystone Modules 19" 48 Port Shielded Rack Mount 1U Black

The patch field in Class E Cat.6 meets the 10” standard for rack installation in a corresponding network cabinet and acts as a central connection point for your network cables A closed metal housing including central grounding connection provide shielding for the 12-port patch panel and LSA rails for mounting the network installation cables The patch panel is designed for 250 MHz / 1GBASE-T and also works with cables and devices in category Cat.5e and Cat.5 thanks to backwards compatibility Patching in accordance with EIA/TIA 568 A & B (LSA rails color-coded accordingly) - Suitable for network cables with AWG 22-26 (solid and stranded conductors) Plug cycles of jack: > 750 - Tensile loading RJ45: 7.7 kg - Dielectric strength: 1000 VDC (contact/contact), 1500 VDC (contact/ground) - Insulation resistance: > 500 MΩ - Contact resistance: < 20 mΩ
