Dormer A002 HSS TiN Coated Jobber Drill 8.60mm OL125mm WL81mm DOR860TIN

General description Series A002 HSS Straight Shank Jobber Drills feature a durable TiN tip coating that enhances tool life and performance. With a 118° self-centering split point, these drills ensure superb hole quality and positional accuracy. They are ideal for drilling in a variety of materials including steel, stainless steel, cast iron, ceramics, and plastics. Technical specifications Material: High-Speed Steel (HSS) with TiN coating Drill Diameter: 8.6mm Flute Length: 81mm Overall Length: 125mm Point Angle: 118° Number of Flutes: 2 Standards Met: BS 328, DIN 338 Cutting Direction: Right-hand Web Thickness: Strengthened Drill Diameter Tolerance: h8 Shank Diameter Tolerance: f11 Spiral Angle: 25-30° Maximum Drilling Depth: 4 times the diameter (4XD) Compatibility and accessories Compatible with standard drill chucks and drill presses Installation Insert the drill bit into a compatible drill chuck Ensure the bit is securely tightened before use Use appropriate safety gear during

118 degree split point - helps with self-centering when used by hand, reduces the push force required Titanium nitride coating - Increases service life of the drill, improves performance when drilling harder materials Improved accuracy - with more accurate holes and a better quality of finish Premium HSS material - Can be used for drilling many materials including steels, aluminium, stainless steel Versatile product - Can be used in many different hand held and machine applications
