Dormer A100 HSS Jobber Drill Bit 1.10mm OL36mm WL14mm DORA100110

General description Dormer A100 Metric HSS jobber drills are designed for general-purpose engineering applications, providing good self-centering capability on a wide range of materials. They are suitable for both hand and machine use, making them versatile tools for various drilling tasks. Technical specifications Material: High-Speed Steel (HSS) Tip diameter: 1.10 mm Working length: 14 mm Overall length: 36 mm Point angle: 118° Shank type: Cylindrical Cutting direction: Right-hand Maximum feed in steel: 0.02 mm/rev at 800 N Nominal tolerance: h8 Cutting profile: Cross-ground with a 3.0 mm diameter cross cut from 3 mm onwards Cutting depth: 4 times the diameter (4xD) Spiral length: 14 mm Compatibility and accessories Compatible with standard drill chucks and drill presses Suitable for drilling in steel and cast iron Installation Insert the drill into a compatible drill chuck Securely tighten the chuck to ensure stability during operation Usage Use appropriate cutting speeds and feeds

Dormer A100 Metric HSS jobber drills are suitable for use in the majority of general purpose engineering applications. They have good self-centring capability on a wide range of materials and are suitable for both hand and machine use. DIN338RNBS328ISO235Tip diameter: 1.10mm.Working length: 14mm.Overall length: 36mm.PTDDORA100110
