£ 118.19
Facet 476087 Silver Top Cylindrical Fuel Pump (STS504)
Prices from
118.19
Featured
|
|
£ 118.19 |
To Shop
|
| COMPARE ALL WEBSHOPS (1) | ||
Description
The Green Spark Plug Company
Facet 476087 Silver Top Cylindrical Fuel Pump - STS504An industry standard for over 60 years, these lightweight compact pumps can be found in almost every conceivable application. With output ranges up to 170.3 liters/hour, .68 bar, these pumps will provide high-performance output for everything from racing cars to heavy duty agricultural and construction machinery. E10 E85 Compatible.Specification:- RoadPump:- 476087EVoltage:- 12vEarth:- Neg Pressure (Psi):- 3.5-5.0Flow:- US Gallons/Hr 30Dry Prime Height in Mtrs:- 0.6Thread Size:- 1/8th nptfOperating Temperature:- -40° to +180° F (all Models)Average Run Time or MTBF:- 6000 hrsLegal Requirements:- Certified & Complies With EEC 95/54 RequirementsLength:-140mmDiameter:- 54mmWeight:-0.7kgFuel Union Installation:- When fitting fuel unions, either wrap PTFE tape around the threads or use Loctite 243 to create a fuel proof sealPlease Note:- Designed and manufactured to automotive specification and not recommended for the maintenance of flightApplicatins:- Motorsport, Marine, AgricultureCross Reference:- PRC3901 AH134776 91864-02800 T41054 30-01007 30-0010600 HC Cargo070003 070058 0149-0554 56ZE7424 D8NN-9350-BB AH134776 247076 6040-0 90606262
Compare webshops (1)
Sort by:
Shops with other sizes
Description
(1)
Facet 476087 Silver Top Cylindrical Fuel Pump - STS504An industry standard for over 60 years, these lightweight compact pumps can be found in almost every conceivable application. With output ranges up to 170.3 liters/hour, .68 bar, these pumps will provide high-performance output for everything from racing cars to heavy duty agricultural and construction machinery. E10 E85 Compatible.Specification:- RoadPump:- 476087EVoltage:- 12vEarth:- Neg Pressure (Psi):- 3.5-5.0Flow:- US Gallons/Hr 30Dry Prime Height in Mtrs:- 0.6Thread Size:- 1/8th nptfOperating Temperature:- -40° to +180° F (all Models)Average Run Time or MTBF:- 6000 hrsLegal Requirements:- Certified & Complies With EEC 95/54 RequirementsLength:-140mmDiameter:- 54mmWeight:-0.7kgFuel Union Installation:- When fitting fuel unions, either wrap PTFE tape around the threads or use Loctite 243 to create a fuel proof sealPlease Note:- Designed and manufactured to automotive specification and not recommended for the maintenance of flightApplicatins:- Motorsport, Marine, AgricultureCross Reference:- PRC3901 AH134776 91864-02800 T41054 30-01007 30-0010600 HC Cargo070003 070058 0149-0554 56ZE7424 D8NN-9350-BB AH134776 247076 6040-0 90606262
Product specifications
