Gallagher Lead Out Cable 2.5 mm 50 m 35 Ohm/km

The Gallagher Electric Fence Ground Cable is a heavy-duty, single-core lead-out and earth cable designed to connect an energiser to the fence and to earth stakes. It features a 2.5 mm galvanised steel wire core with double insulation and a flexible outer coating, suitable for above-ground and underground connections, including under gates and passages. Practical metre markings along the cable simplify measuring and stripping during installation. For distances over 30 metres or energisers with high pulse energy, the 2.5 mm cable is recommended; for distances under 30 metres, the 1.6 mm cable is advised. The cable length is 50 metres and it is recommended to install the cable inside plastic conduit for added protection.

Features

• Single-core earthing/lead-out cable
• Connects energiser to fence and earth stakes
• Suitable for underground connections at gates
• Flexible outer coating with metre markings
• Heavy-duty galvanised steel wire core
• Length 50 m

Technical specifications

• Core diameter: 2.5 mm
• Inner insulation diameter: 4.6 mm ±0.2
• Outer insulation diameter: 6.9 mm ±0.2
• Length: 50 m
• Available in 25 m and 100 m
