Heschen M30 Capacitive Proximity Sensor Switch, Non Shield Type, LJC30A3 H Z/BY, Detector 1 15mm, 10 30VDC 200mA, PNP Normally Open(NO), 3 Wires

Premium M30 AC Sensor: Model LJC30A3-H-Z/BY. Operating on a wide voltage range of DC 10-30V with a powerful 200mA output. This high-capacity load allows it to directly control small relays, contactors, or PLC inputs with exceptional stability. 1-15mm Sensing Distance: This capacitive proximity switch can detect both metallic and non-metallic objects, such as wood, plastic, glass, and liquids. The built-in potentiometer allows for easy sensitivity adjustment to filter out interference or fine-tune for specific materials. Normally Open (NO) Configuration: In the NO state, the circuit remains disconnected until an object enters the sensing range. This 3-wire DC design simplifies wiring and is ideal for object counting, liquid level alarms, and automated triggering. Rugged Non-Shielded Design: Constructed with high-quality components and a robust shell for superior impact resistance. The non-shielded (unflush) head provides higher sensitivity and a wider detection angle, perfect for complex industrial automation environments. Wide Application Range: Essential for automatic control, positioning, counting, and speed monitoring in industries such as packaging, printing, and manufacturing. Available in various specifications (NO/NC, AC/DC) to meet all your project requirements.
