Irwin HSS TCT Tip Drill Bit 5.5mm OL93mm WL57mm IRW10502646

ManoMano

General description The Irwin HSS TCT (Tungsten Carbide Tipped) drill bit is designed for precision drilling in hardened steel, cast iron, bronze alloys, and manganese alloyed steel using stationary machines. The C2 Carbide Tip allows for drilling in materials with a hardness of up to 50 Rockwell C, featuring a four-faceted ground design that ensures low drilling pressure and perfect centering. The drill bit's body is constructed from Chrome Vanadium Steel, hardened to 56 Rockwell C, providing durability and strength. Technical specifications Diameter: 5.5mm Total length: 93mm Working length: 57mm Body material: Chrome Vanadium Steel Hardness of body: 56 Rockwell C Tip material: C2 Carbide Maximum hardness for drilling: 50 Rockwell C Usage When using the Irwin HSS TCT tip drill bit, it is essential to apply a coolant to extend the drill bit's lifespan. Irwin recommends using a 3-6% emulsion as a coolant during drilling operations. Other information

Power Tools Direct

The Irwin Metric TCT (Tungsten Carbide Tipped) Drill Bits offer precision drilling with stationary machines in hardened steel cast iron bronze alloys and manganese alloyed steel. The C2 Carbide Tip will drill hardened material up to a hardness of 50 Rockwell C and is four facetted ground for low drilling pressure and perfect centring. The body of the drill bit is made from Chrome Vanadium Steel hardened to 56 Rockwell C. A coolant should always be used when drilling with TCT twist drill bits. Irwin suggest the use of a 3- 6% emulsion. The coolant will extend the lifetime of the drill bit.Irwin HSS TCT tip drill bit. Specifications:Diameter: 5.5mm.Total length: 93mm.Working Length: 57mm.PTDIRW10502646

Amazon

C2 carbide tip Ideal for drilling hard and abrasive materials Chrome vanadium steel Diamond-ground 4 face carbide tip Designed for use in stationary drills IRWIN, 133 years of ingenuity and high quality, Manufacturer: IRWIN
