KnightsBridge 230V IP20 Fixed GU10 Fire Rated Downlight Brushed Chrome

The Fixed GU10 Fire-Rated Downlight in Brushed Chrome is an elegant and functional lighting solution designed to enhance your indoor spaces while ensuring safety and durability. This downlight operates on 230V with a maximum wattage of 35W, making it versatile for both LED and halogen bulb applications.

Installation Features

The downlight features a fast-fix installation mechanism, ensuring that you can set it up quickly and easily. It is equipped with push-fit terminals that facilitate straightforward wiring, and a loop in/loop out capability, allowing for seamless integration with existing lighting circuits. This user-friendly design is ideal for both DIY enthusiasts and professional installers.

Compatibility

This fixture is compatible with GU10 lamp types and can accommodate both LED and halogen bulbs. Notably, it is dimmable, which adds to its versatility, though this feature is dependent on the specific lamp chosen. It is essential to note that the maximum wattage for the installed lamp is 35W, and no bulb is included with the purchase, allowing you to select the lighting intensity that best suits your needs.

Safety and Certification

The downlight has undergone rigorous testing and is rated for fire resistance, certified to withstand 30, 60, and 90 minutes, ensuring that your spaces remain secure in the event of a fire. Additionally, it is IC rated when used with a maximum 6W LED lamp, indicating that it can safely be installed in insulated ceilings without risking overheating.

Construction and Design

Constructed from high-quality pressed steel, this downlight not only guarantees durability but also presents a sleek aesthetic. The brushed chrome finish adds a modern touch, making it an excellent fit for contemporary interiors. Its dimensions are compact yet impactful, with a diameter of 85mm, a profile projection of just 4mm, and a recessed depth of 100mm, requiring a minimum void of 126mm for installation. The cut-out diameter necessary for fitting is 65mm.

Specifications

- Finish: Brushed Chrome

- Material: Pressed Steel

- Height: 76mm

- Projection: 4mm

- Diameter: 85mm

- Weight: 0.25kg

- Class: I

- IP Rating: IP20

- Primary Voltage: 230V 50Hz

- Warranty: 3 Years

This Fixed GU10 Fire-Rated Downlight in Brushed Chrome is not just a lighting fixture; it is a blend of safety, style, and functionality, perfect for illuminating various settings in your home or workplace while adhering to the highest safety standards.
