MasonMate Medium Duty Projecting Shield Anchor M6 x 60mm

General description MasonMate Medium-Duty Projecting Shield Anchors are designed for reliable fastening in masonry and concrete applications. These anchors feature an internally threaded design, making them suitable for various construction materials. Technical specifications Diameter: M6 Length: 60mm Anchor Hole Size: 12mm Shield Length: 45mm Thread Diameter: 6mm Fastens Up To: 60mm Bolt Length: 115mm Min. Hole Depth: 50mm Box Quantity: 50 Anchor Body Grade: 5.8 Compatibility and accessories Suitable for use in concrete, concrete blocks, solid brick, and solid stone Other information Zinc plated for increased durability Accommodates variations in hole size

MasonMate Medium-Duty Shield Anchors (projecting studtype) are internally threaded for fixing into masonry and concrete. Zinc plated for increased durability. Anchor body grade 5.8. Suitable for variations in hole size. For use in concrete concrete blocks solid brick and solid stone.These MasonMate Medium-Duty Projecting Shield Anchors have the following specifications: Diameter: M6.Length: 60mm.Anchor Hole Size: 12mm.Shield Length: 45mm.Thread Diameter: 6mm.Fastens Up To: 60mm.Bolt Length: 115mm.Min. Hole Depth: 50mm.Box Qty.: 50.PTDMAMSAPM660
