NGK R2525 10 5281 Spark Plug Racing R252510

MotardInn

Ngk R2525-10 5281 Spark Plug. NGK Racing Series plugs are engineered to withstand the harshest engine conditions. Fine wire platinum tipped center electrode improves ignitability, increases durability and enhances anti fouling capabilities. Special insulator nose configurations improve throttle response. Corrugated ribs prevent flashover. Pure alumina silicate ceramic insulator, provides superior strength and better heat transfer. Copper core aids in heat removal. Triple seals prevent leakage. Specifications:Shell: - Thread Diameter: 12mm- Thread Pitch: 1.25mm- Seat Type: Gasket- Reach: 19mm (3/4´´)- Hex Size: 5/8´´ (16mm)- Terminal Type: Removable Nut- Overall Height: ISO- Gap: 024´´ (0.6mm)- Center Electrode- Material: Platinum- Type: Fine Wire- Size: 1.3mm- Projection: Non-Projected- Ground Electrode- Material: Nickel- Type: Slant- Quantity: 1- Resistor: Yes- Resistor Value: 5k Ohm- Heat Range: 10- Torque SpecsCast Iron: 10.8-18 lb. ft. Aluminum: 10.8-14.5 lb. ft. . tradeinn Motardinn

The Green Spark Plug Company

The NGK R2525-10 is part of the NGK Laser Platinum range.NGK Laser Platinum is an original-equipment long-life plug with platinum on both the centre and ground electrodes. Platinum's high melting point and resistance to erosion mean the gap barely grows over the service interval, so the plug keeps its factory ignition performance until the scheduled change. Designed to be fitted as the direct replacement where the manufacturer specifies this part number, especially on engines with distributorless or waste-spark ignition where the ground electrode wears as fast as the centre. Cross reference (approximate equivalents): Champion A51R, A55C, A55R, A57C. Equivalents from NGK’s 2024 cross-reference chart – check thread size, reach and seat type before fitting.

Amazon

Designed for motorsport use: Specially developed and produced for the extreme conditions of racing. Specially developed earth electrode material and shape to withstand higher temperatures, pressures and vibrations in the combustion chamber. Highest load capacity: Extreme heat protection and vibration to resistance to withstand higher loads. Note: Please observe the general fitting instructions before installation! Scope of delivery: NGK Racing spark plug R2525-10
