Schneider Electric TeSys GV2 and GV3 Auxiliary Contact Block 1 NO + NC GVAN11

Telemecanique GVAN11 is an auxiliary contact block for the TeSys range, configured with one normally open (N/O) and one normally closed (N/C) contact. It is designed for left-side mounting and offers a compact 1F+1O pole configuration, making it suitable for a variety of electrical control applications. The device is compatible with GV2L, GV2LE, GV2ME, GV2P, GV2RT, GV3L and GV3P series products, enabling straightforward integration into existing control schemes. Key electrical ratings include a rated insulation voltage of 600 V and a rated operating voltage spanning 48–690 V AC or 24–240 V DC. The conventional thermal current is 6 A, aligning with typical control-circuit requirements within industrial environments. The GVAN11 sits within the broader TeSys product family and is designed to meet modern standards and application needs.

This auxiliary block is part of a refreshed design approach for machines, reflecting a new modern look and feel while emphasising reliability in electro domestic and HVAC contexts. It aligns with IEC60335-1 compliance, supports improved fire resistance, and is designed to withstand dust exposure in operation. The device supports a digital customer experience for technical documentation and can be referenced in maintenance guides via EcoStruxure facilities.

Features

• 1 normally open and 1 normally closed contact
• Left-hand side mounting, side mounting
• 1F+1O poles
• Rated insulation voltage 600 V
• 48–690 V AC / 24–240 V DC operating voltage
• Conventional thermal current 6 A

Usage

1. Install GVAN11 on the left side of the compatible TeSys assembly.
2. Connect control wiring to the N/O and N/C terminals as required.
3. Integrate with GV2L/GV2LE/GV2ME/GV2P/GV2RT/GV3L/GV3P series as applicable.
4. Verify operating voltage and current within specified ranges.
5. Ensure compliance with IEC60335-1 and maintain dustproof conditions.
