Sealey Bandsaw 400mm Horizontal Hydraulic Arm
Featured
|
£ 3,604.27 |
To Shop
|
|
£ 4,276.74 |
To Shop
|
Description
Manufactured to comply with the Supply of Machinery (Safety) Directives 1992 (and amendments) and fully CE approved, this saw machine is designed for professional use in both industrial and agricultural engineering applications. Its robust construction and advanced features ensure high performance and safety during operation.
Safety Features
The saw arm is equipped with hydraulic damping, which prevents it from dropping onto the workpiece unexpectedly, thereby facilitating a smooth cutting experience. The machine has a built-in coolant fluid system that aids in maintaining optimal blade temperature and effectiveness during prolonged use. Additional safety measures include:
- A 24V system for coolant pump and motor controls, enhancing operator safety.
- An over-current sensor integrated into the heavy-duty single-phase electric motor, which automatically cuts the power in the event of a blade jam to prevent accidents.
- All blade and pulley covers are protected by safety switches, providing an extra layer of security during operation.
Cutting Capacity and Performance
This model, identified as the SM353CE, boasts a large cutting capacity that caters to a variety of shapes and sizes, making it versatile for different tasks. The impressive specifications include:
- Capacity at 90° for Round: Ø228mm
- Capacity at 90° for Square/Rectangular (H x W): 228 x 355mm
- Capacity at 45° for Round: Ø152mm
- Capacity at 45° for Square/Rectangular (H x W): 228 x 152mm
Equipped with a blade size of 3035 x 27 x 0.9mm, this saw provides flexibility with multiple blade speeds of 21, 33, 42, and 59 m/min. The no-load speed is rated at 1400 rpm. This range of speeds allows the operator to adjust according to the material being cut, ensuring clean and precise results.
Construction and Design
The saw bed is precision machined from cast iron, providing immense stability and durability, which is crucial for maintaining accuracy during operation. The hydraulic feed saw arm offers greater control over cutting depth and speed, resulting in clean and professional outcomes.
Additional Information
Weighing in at 279kg, this machine is substantial and designed for heavy-duty use. It is important to note that extra assistance will be required at the delivery point to ensure safe handling. The saw dimensions are as follows: length 565mm, height 1110mm, and weight 337kg.
With a warranty of 1 year included, this cutting machine stands out in terms of safety, performance, and durability, making it an excellent choice for professionals seeking a reliable solution for their cutting needs.
Description
Manufactured to comply with the Supply of Machinery (Safety) Directives 1992 (and amendments) and fully CE approved, this saw machine is designed for professional use in both industrial and agricultural engineering applications. Its robust construction and advanced features ensure high performance and safety during operation.
Safety Features
The saw arm is equipped with hydraulic damping, which prevents it from dropping onto the workpiece unexpectedly, thereby facilitating a smooth cutting experience. The machine has a built-in coolant fluid system that aids in maintaining optimal blade temperature and effectiveness during prolonged use. Additional safety measures include:
- A 24V system for coolant pump and motor controls, enhancing operator safety.
- An over-current sensor integrated into the heavy-duty single-phase electric motor, which automatically cuts the power in the event of a blade jam to prevent accidents.
- All blade and pulley covers are protected by safety switches, providing an extra layer of security during operation.
Cutting Capacity and Performance
This model, identified as the SM353CE, boasts a large cutting capacity that caters to a variety of shapes and sizes, making it versatile for different tasks. The impressive specifications include:
- Capacity at 90° for Round: Ø228mm
- Capacity at 90° for Square/Rectangular (H x W): 228 x 355mm
- Capacity at 45° for Round: Ø152mm
- Capacity at 45° for Square/Rectangular (H x W): 228 x 152mm
Equipped with a blade size of 3035 x 27 x 0.9mm, this saw provides flexibility with multiple blade speeds of 21, 33, 42, and 59 m/min. The no-load speed is rated at 1400 rpm. This range of speeds allows the operator to adjust according to the material being cut, ensuring clean and precise results.
Construction and Design
The saw bed is precision machined from cast iron, providing immense stability and durability, which is crucial for maintaining accuracy during operation. The hydraulic feed saw arm offers greater control over cutting depth and speed, resulting in clean and professional outcomes.
Additional Information
Weighing in at 279kg, this machine is substantial and designed for heavy-duty use. It is important to note that extra assistance will be required at the delivery point to ensure safe handling. The saw dimensions are as follows: length 565mm, height 1110mm, and weight 337kg.
With a warranty of 1 year included, this cutting machine stands out in terms of safety, performance, and durability, making it an excellent choice for professionals seeking a reliable solution for their cutting needs.
Product specifications
