Sealey Fixed Frame Engine Crane with Extendable Legs 3 Tonne

The PH30 Heavy-Duty Lifting Device is an essential tool for heavy commercial, industrial, and workshop environments. Engineered for maximum efficiency and safety, this lifting solution is designed to handle substantial loads with ease.

Impressive Lifting Capacity and Versatility

This lifting device boasts a remarkable lifting capacity of 3000kg at a jib extension of 1200mm. With four adjustable jib positions, you can adapt the lift to meet various requirements:

- Lifting Capacity at Jib Position 1 (1200mm): 3000kg

- Lifting Capacity at Jib Position 2 (1400mm): 2000kg

- Lifting Capacity at Jib Position 3 (1610mm): 1500kg

- Lifting Capacity at Jib Position 4 (1820mm): 1000kg

The maximum lift heights at these positions are equally impressive, with a maximum of 2220mm achievable at Jib Position 4.

Enhanced Stability and Safety

Stability is a critical consideration when operating at maximum jib extensions. The extendable heavy-duty legs provide added support, ensuring safe and efficient operation during heavy lifting tasks. The device is equipped with heavy-duty castors for smooth mobility, allowing you to easily maneuver it to where it's needed most. Additionally, the pump access is conveniently positioned on the side, facilitating safe handling of heavy loads.

<a class='cat-link' href='https://bigshopper.co.uk/brand/durable/'>Durable</a> Design and Construction

Constructed with robust materials, the PH30 is built to endure the rigors of constant use in demanding environments. It has a net weight of 155kg, ensuring that it is sturdy enough to handle significant loads. With dimensions of 830mm in length and 330mm in height when assembled, this lifting device maintains a compact profile while delivering powerful performance.

Assembly and Handling Instructions

The PH30 is delivered in a knock-down form, which helps reduce transportation costs. Some self-assembly will be required to set up the device, but the process is straightforward. Due to its weight, extra assistance is recommended at the delivery point to ensure safe handling upon arrival.

Technical Specifications

- Height with Jib Down: 1610mm

- Height of Frame: 195mm

- Length of Legs Extended: 1940mm

- Rear Width with Legs Extended: 780mm

- Width of Front Frame: 855mm

- Width Inside Front Frame: 700mm

The PH30 Heavy-Duty Lifting Device is a reliable choice for anyone in need of a powerful, versatile, and safe lifting solution. Whether for workshop use or industrial applications, it delivers performance and stability that you can depend on.
