Telemecanique K1D024M Harmony k body for sel. voltmeter 3L 45DEG 12A Ø22mm fixing

ManoMano

General description The Telemecanique K1D024M Harmony K is a body designed for a voltmeter switch, suitable for measuring voltage between three phases. It features a conventional thermal current rating of 12 A and includes a fixing plate and contact blocks as part of its subassembly. Technical specifications Conventional thermal current: 12 A Angular positions: 0°, 45°, 90°, 135° Product mass: 0.126 kg Fixing method: Hole Ø 22 mm Electrical connection: Flexible captive screw clamp terminals, 2 x 1.5 mm≤ / Rigid captive screw clamp terminals, 1 x 2.5 mm≤ Installation Product mounting: Front mounting Usage Switch Function: Voltmeter switch Position 0: With Off position

Radwell UK

CAM SWITCH CONTACT BLOCK, BODY FOR VOLTMETER SWITCH, 3L - 45°, 12 A, FOR Ø 22 MM
