TENMA 21 10156 Angled Chisel Soldering Tip 4.0mm

A compact and lightweight probe for the analysis and troubleshooting of logic circuits. The probe will recognise high, intermediate and low level pulses in DTL, TTL, HTL and CMOS logic circuits. Works as a pulse detector, pulse stretcher and a pulse memory. Circuit powered; supplied with test clips Detects high speed pulse trains or single events, LED indicators: HI (red), LO (green), pulses/memory (yellow) and square wave (red and green) Selectable pulse detection or pulse memory mode, Selectable TTL or CMOS operation Overload protection, Memory will latch on the first rising or falling transition
