TIMCO Corefix 5.0 x 100mm Pack of 4 Heavy Duty Dot and DAP Platerboard Wall Fixing

General description This highly effective and innovative product was developed to safely secure heavy loads, including cabinets and brackets, to dot and dab plasterboard walls or boards supported on battens. Quick to install, this patented product works by securing the load to the brick or block behind the board, bridging the problematic gap that dot and dab creates, by way of a zinc plated steel tube insert. Technical specifications Pack Dimensions (L x W x H): 10 x 82 x 210 mm Pack Weight: 0.084 kg Head Type: Countersunk Drill Hole Ø: 10 mm Corrosion Rating: 1 (Clean, dry & low humidity environments) Recess Type: Pozi Plug Size: 10 x 95 mm Driver Bit Size: PZ2 Screw Size: 5.0 x 100 mm Substrates: Brick, Block, Stone Drill Hole Depth: 100 mm Core Insert Ø x L: 8.0 x 50 mm Material: Carbon Steel Screw, Impact Resistant PP Copolymer Plug, Carbon Steel Core Plug Pack Quantity: 4 Installation Fast installation, no specialist tools required Tools needed: drill, 10mm bit, hammer &
