Dormer A002 10.30MM HSS Straight Shank Jobber Drills TiN Tipped
Description
Zoro Tools
Series A002 HSS Straight Shank Jobber Drill feature a hardy TiN tip coating for increased tool life and performance with 118 self-centering split point for superb hole quality and positional accuracy. Ideal for use on steel, stainless, cast iron, ceramics, plastics and many other materials. They are available in size range: 1.00mm - 16.00mm and manufactured to BS328: Part 1: 1986, DIN 338 standards. Features and Benefits Efficient point design for superior cutting action, reduced axial force and accurate centreing Titanium nitrile (TiN) coating offers low friction and resists wear for faster cutting speeds All Surfaces are ground for consistent precision 118 self-centering split point offers excellent hole quality and positional accuracy Bright body finish improves cutting performance on ductile materials Optimised helix for greater stiffness across diameter range Geometry of flute design improved for efficient chip form and evacuation Optimised for strength and rigidity with an easy feed Easily identifiable markings allow better in-situ identification Standards Manufactured to BS328: Part 1: 1986, DIN 338 standards Typical Applications Wood Composite Soft metals Steel Iron Plastics Drilling Tapping Notes Available in size range: 1.00mm - 16.00mm Also available in Imperial measurements
Description
(2)
Series A002 HSS Straight Shank Jobber Drill feature a hardy TiN tip coating for increased tool life and performance with 118 self-centering split point for superb hole quality and positional accuracy. Ideal for use on steel, stainless, cast iron, ceramics, plastics and many other materials. They are available in size range: 1.00mm - 16.00mm and manufactured to BS328: Part 1: 1986, DIN 338 standards. Features and Benefits Efficient point design for superior cutting action, reduced axial force and accurate centreing Titanium nitrile (TiN) coating offers low friction and resists wear for faster cutting speeds All Surfaces are ground for consistent precision 118 self-centering split point offers excellent hole quality and positional accuracy Bright body finish improves cutting performance on ductile materials Optimised helix for greater stiffness across diameter range Geometry of flute design improved for efficient chip form and evacuation Optimised for strength and rigidity with an easy feed Easily identifiable markings allow better in-situ identification Standards Manufactured to BS328: Part 1: 1986, DIN 338 standards Typical Applications Wood Composite Soft metals Steel Iron Plastics Drilling Tapping Notes Available in size range: 1.00mm - 16.00mm Also available in Imperial measurements
ManoManoDormer: A002 HSS-TiN Coated Jobbe Dill 10.30mm OL133mm WL87mm DOR1030TIN Dormer Metric A002 TiN Jobber Drill Bits have a TiN tip coating for increased tool life and performance. It has a self-centring split point for superb hole quality and positional accuracy. It will drill steel, stainless, cast iron, ceramics, plastics and many other materials with ease. Made to DIN 338RN/BS328/ISO 235 standards. PLEASE NOTE ALL sizes under 2.0mm are NOT TiN Coated. Tip diameter 10.30mm. Working length 87mm. Overall length 133mm. MPN: DOR1030TIN EAN: 7320760351482 A002 HSS-TiN Coated Jobbe Dill 10.30mm OL133mm WL87mm DOR1030TIN Attributes: MFR Part No.: DOR1030TIN Overall Length: 133mm Tip Diameter: 10.3mm Working Length: 87mm
Product specifications
