ESP 4 Zone Fire Panel

ESP
ESP 4 Zone Fire Panel

Prices from

137.02

	£ 137.02	To Shop
	£ 155.64	To Shop

Description

Electrical World 4 Zone ABS Conventional Fire Panel4 programmable zones Active end of line monitoring and head removal 30 fire detectors per zone Unlimited number of call points per zone Integral sound alarm button 'Class change' facility Enable/disable security key One man walk test facility Volt free fire change over relay Volt free fault change over relay Individual sounder circuit fault ID Individual zone/sounder isolate CE certified to EN54 P2/4 Requires only 1x12v battery MAG4P - ABS casingTechnical Specification:Inputs: Max Detectors per Zone: 30Thresholds for Zone Conditions: 0 - 2 mA (Fault condition) 2 - 6 mA (Normal condition) 6 - 110 mA (Fire condition) 110 mA - Short (Fault condition)Power: Mains Fail Consumption : 50mAMains Supply: 230 VAC ± 10%Standby Supply: 1 x 7ah 12V S.L.A. BatteryPower Availability: 0.7 ampsOutputs: Sounder 1: 24V (max 300mA fused)Sounder 2: 24V (max 300mA fused)Fault/Fire Relay: Volt free 500mA @ 24V (max load)Auxiliary Output: 24VDC (300mA fused)Environment: Working Temperature: 0 to 40ºCStorage Temperature: -20 to 60ºCHumidity: 0 - 95%Dimensions MAG4P: 340 x 290 x 100mmDimensions MAG4: 320 x 220 x 80mmWeight: MAG4P - 2.5Kg MAG4 - 3.5Kg

Compare webshops (2)

Shop

Price

£ 137.02

To Shop

£ 155.64

To Shop

Description (2)

Electrical World

4 Zone ABS Conventional Fire Panel4 programmable zones Active end of line monitoring and head removal 30 fire detectors per zone Unlimited number of call points per zone Integral sound alarm button 'Class change' facility Enable/disable security key One man walk test facility Volt free fire change over relay Volt free fault change over relay Individual sounder circuit fault ID Individual zone/sounder isolate CE certified to EN54 P2/4 Requires only 1x12v battery MAG4P - ABS casingTechnical Specification:Inputs: Max Detectors per Zone: 30Thresholds for Zone Conditions: 0 - 2 mA (Fault condition) 2 - 6 mA (Normal condition) 6 - 110 mA (Fire condition) 110 mA - Short (Fault condition)Power: Mains Fail Consumption : 50mAMains Supply: 230 VAC ± 10%Standby Supply: 1 x 7ah 12V S.L.A. BatteryPower Availability: 0.7 ampsOutputs: Sounder 1: 24V (max 300mA fused)Sounder 2: 24V (max 300mA fused)Fault/Fire Relay: Volt free 500mA @ 24V (max load)Auxiliary Output: 24VDC (300mA fused)Environment: Working Temperature: 0 to 40ºCStorage Temperature: -20 to 60ºCHumidity: 0 - 95%Dimensions MAG4P: 340 x 290 x 100mmDimensions MAG4: 320 x 220 x 80mmWeight: MAG4P - 2.5Kg MAG4 - 3.5Kg

Expert Electrical

ESP MAG4P 4 Zone Fire Panel
