Schneider Electric TeSys GV2 and GV3 Auxiliary Contact 1 NO + (Fault) GVAD1010

The GVAD1010 is an auxiliary contact block designed for use with the TeSys range. It features a 2F pole configuration and supports fault signal operation. The device uses screw clamp terminals and is compatible with a range of GV system modules, including GV2L, GV2LE, GV2ME, GV2P, GV2RT, GV3L, and GV3P. It is rated for 6 A and supports multiple voltage inputs, including 48–690 VAC and 24–240 VDC, with a 1NO/1NO configuration. The product aligns with IEC60335-1 compliance, offering improved fire resistance and suitability for electro domestic and HVAC applications, and reflects a new modern look and feel across related machinery components.

Features

• 2F pole auxiliary contact block
• Fault signal operation
• Screw clamp terminals
• Compatible with GV2L, GV2LE, GV2ME, GV2P, GV2RT, GV3L, GV3P
• 6 A at 48–690 VAC or 24–240 VDC

Technical specifications

• Abbreviated name: GVAD
• Connection method: Screw clamp terminals
• Cable options: 1 cable 1–2.5 mm²; 2 cables 1–2.5 mm² (rigid)
• New look for electro domestic and HVAC settings
• IEC60335-1 compliant with improved fire resistance and dustproof auxiliaries
• Compatible with GV2L, GV2LE, GV2ME, GV2P, GV2RT, GV3L, GV3P
