TIMco 00110TCON ZYP Multi Fix Concrete Screw 7.5 x 110 Yellow (Box of 100)

A Rapid And Effective Light Duty Anchoring System For Fixing Into Concrete Brick Stone Concrete Block And Wood. This Through Fixing Provides A Single Solution And Replaces Traditional Fixings Such As Nylon Frame And Hammer Fixings. Designed To Replace Traditional Masonry FixingsTx30 Tx Drive Recess To Reduce Driver Wear & Prevent Camming-OutSerrated V-Threads To Achieve Optimum Insertion Into All Masonry TypesZinc Plated And Yellow Passivated For Increased Corrosion Resistance High-Low Thread On First 30Mm To Aid Insertion And Reduce TorqueIdeal For Fitting Windows And Door FramesSee `More Information` below for sizing and Colour detailsSpecificationPackaged Width = 88mmFixture Hole Diameter (metric) = 8mmPackaged Height = 80mmDrill Hole Diameter (metric) = 6mmHead = Flat Countersunk with RibsLength (metric) = 110mmDiameter (metric) = 7.5mmFinish = Zinc & YellowThread Diameter (metric) = 7.5mmPackaged Weight = 2.147kgPackaged Length = 132mmMax Fixture Thickness (metric) = N/AType of Recess = TX DriveMin Embedment Depth (metric) = 50mmPTDTIM00110TCON

Designed to replace traditional masonry fixings TX30 TX Drive recess to reduce driver wear & prevent camming-out Serrated V-threads to achieve optimum insertion into all masonry types Zinc plated and yellow passivated for increased corrosion resistance High-Low thread on first 30mm to aid insertion and reduce torque Ideal for fitting windows and door frames Flat countersunk head with five locking ribs
