Dormer A108 Jobber Drill Split Point for Stainless Steel 5.00mm OL86mm WL52mm DOR500QS

ManoMano

General description The Dormer A108 Metric Split Point HSS Jobber Drill Bits are specifically designed for machining stainless steels. Featuring a quick spiral helix, these drill bits enable rapid swarf removal, making them ideal for drilling Austenitic stainless steel. Technical specifications Tip diameter: 5.0mm Working length: 52mm Overall length: 86mm Flute Geometry: Quick Helix, Right hand spiral Point Angle: 135° (for sizes up to 1.5mm: 135° Split Point, 1.6mm and above: 135°) Surface Treatment: Blue Material: High Speed Steel Manufactured to standards: DIN 338 RW / BS328 / ISO 235

Power Tools Direct

The Dormer A108 Metric Split Point HSS Jobber Drill Bits are designed specifically for machining stainless steels. The quick spiral helix enables rapid swarf removal. Manufactured to DIN 338 RW / BS328 / ISO 235. Specification Flute Geometry: Quick Helix Right hand spiral.Point Angle: 135°: up to 1.5mm: 135° Split Point 1.6mm 1/16 and above.Surface Treatment: Blue.Material: High Speed Steel.Tip diameter: 5.0mm.Working length: 52mm.Overall length: 86mm.PTDDOR500QS

Amazon

High Speed Steel (HSS) provides good hot hardness when drilling 135 degree split point provides self centering, low thrust and easier penetration Strong flute designed specifically for drilling stainless steels Steam oxide finish reduces built-up-edge and helps lubricity Primary for use on machines, but can be used in hand held applications
