Indexa S25T SDUCL 11 Boring Bar
Description
ManoMano
@@@lm7pDMz3S6wTQxF4NMvsOKEmjlCC/xNY@@@: S25T SDUCL 11 Boing Ba 93 approach for 7 positive 55 rhombic inserts. MPN: IND1067750K EAN: 5036140081901 S25T SDUCL 11 Boing Ba Attributes: Approach Angle: 93° Centre to Cutting Tip: 17mm Clearance Angle: 7° Coolant Delivery: External Cutting Direction: Left Hand Cutting Height (h1): 11.5mm ISO Designation: S25T SDUCL 11 Insert Cutting Edge Length: 11.6mm Insert Holding Type: Screw-On Insert Inscribed Circle: 9.52mm Insert Shape: 55° Rhombic Insert Size: 11T3mm Insert Style: DC_Tmm Inserts Included: None MFR Part No.: S25T-SDUCL11 Minimum Bore Diameter (D): 31mm Neck Length (l2): 40mm Overall Length (l1): 300mm Set Type: Individual Boring Bar Shank Diameter (d): 25mm Shank Height (h): 23mm Shank Material: Steel Toolholder Style: DC_T
Description
(2)
@@@lm7pDMz3S6wTQxF4NMvsOKEmjlCC/xNY@@@: S25T SDUCL 11 Boing Ba 93 approach for 7 positive 55 rhombic inserts. MPN: IND1067750K EAN: 5036140081901 S25T SDUCL 11 Boing Ba Attributes: Approach Angle: 93° Centre to Cutting Tip: 17mm Clearance Angle: 7° Coolant Delivery: External Cutting Direction: Left Hand Cutting Height (h1): 11.5mm ISO Designation: S25T SDUCL 11 Insert Cutting Edge Length: 11.6mm Insert Holding Type: Screw-On Insert Inscribed Circle: 9.52mm Insert Shape: 55° Rhombic Insert Size: 11T3mm Insert Style: DC_Tmm Inserts Included: None MFR Part No.: S25T-SDUCL11 Minimum Bore Diameter (D): 31mm Neck Length (l2): 40mm Overall Length (l1): 300mm Set Type: Individual Boring Bar Shank Diameter (d): 25mm Shank Height (h): 23mm Shank Material: Steel Toolholder Style: DC_T
Zoro Tools93 approach for 7 positive 55 rhombic inserts.
