Indexa SVJNR 2525M12 External Toolholder
Description
ManoMano
Indexa: SVJNR 2525M12 External Toolholder 93 approach for 35 negative rhombic inserts. MPN: IND1065850K EAN: 5036140081307 SVJNR 2525M12 External Toolholder Attributes: Approach Angle: 93° Clearance Angle: 0° Coolant Delivery: External Cutting Direction: Right Hand Cutting Height (h1): 25mm Head Length (l2): 31mm ISO Designation: SVLBR 2020K16 Insert Cutting Edge Length: 16mm Insert Holding Type: Screw-On Insert Shape: 35° Rhombic Insert Size: 12T3 Insert Style: VN_G Inserts Included: None Neck Length: 31mm Overall Length (l1): 150mm Set Type: Individual Toolholder Shank Height (h): 25mm Shank Material: Steel Shank Style: Straight Shank Width (b): 25mm Side to Cutting Tip (f): 32mm Toolholder Style: SVJN
Description
(2)
Indexa: SVJNR 2525M12 External Toolholder 93 approach for 35 negative rhombic inserts. MPN: IND1065850K EAN: 5036140081307 SVJNR 2525M12 External Toolholder Attributes: Approach Angle: 93° Clearance Angle: 0° Coolant Delivery: External Cutting Direction: Right Hand Cutting Height (h1): 25mm Head Length (l2): 31mm ISO Designation: SVLBR 2020K16 Insert Cutting Edge Length: 16mm Insert Holding Type: Screw-On Insert Shape: 35° Rhombic Insert Size: 12T3 Insert Style: VN_G Inserts Included: None Neck Length: 31mm Overall Length (l1): 150mm Set Type: Individual Toolholder Shank Height (h): 25mm Shank Material: Steel Shank Style: Straight Shank Width (b): 25mm Side to Cutting Tip (f): 32mm Toolholder Style: SVJN
Zoro Tools93 approach for 35 negative rhombic inserts.
Product specifications
