Sealey Premier Air Compressor 270L Belt Drive 7.5hp 3ph

The heavy-duty 3-phase compressor is ideal for professional workshops, designed to meet the demanding requirements of various industrial applications. This robust compressor features a triple-cylinder pump system powered by a 7.5hp motor, ensuring optimal performance while maintaining lower running costs compared to traditional single-stage, single-phase models.

Key Features

- Superior Air Displacement: With an air displacement rate of 29.7 cfm (840 L/min), this compressor can handle significant air demand, making it suitable for a variety of tools and equipment in a workshop setting.

- Maximum Free Air Delivery: The compressor achieves a maximum free air delivery of 26.2 cfm (742 L/min), providing efficient air flow for sustained use.

- Peak Pressure Performance: Operating at a maximum pressure of 145 psi (10 bar), this compressor ensures that tools receive a consistent and powerful air supply, enhancing productivity and efficiency.

Construction and Durability

The compressor is built with heavy-duty, full cast cylinders that are topped with alloy heads. This design not only enhances durability but also ensures improved heat dissipation, which is crucial for the long life of the equipment. The heavy-duty drive guards provide additional protection for the belt and flywheel, which are specifically designed to force air over the pump to aid in cooling.

User-Friendly Design

One of the notable features of this compressor is the inclusion of a drain valve that allows for easy release of condensed water build-up in the tank. This ensures that the compressor operates efficiently and prolongs its service life by preventing corrosion and damage.

Technical Specifications

- Air Displacement: 29.7 cfm (840 L/min)

- Maximum Free Air Delivery: 26.2 cfm (742 L/min)

- Maximum Pressure: 145 psi (10 bar)

- Motor Output: 7.5 hp

- Minimum Rated Supply: 32 A

- Nett Weight: 193 kg

- Outlet: 1/2" BSP

- Phase: 3ph

- Receiver Capacity: 270 L

- Size (W x D x H): 1500 x 620 x 1080 mm

- Speed: 970 rpm

- Supply Voltage: 415 V

Certifications and Warranty

This compressor is supplied with full CE certification, including test certificates and an operating/maintenance manual, ensuring compliance with industry standards. It also comes with a 2-year guarantee, giving users peace of mind regarding quality and reliability.

In summary, the heavy-duty 3-phase compressor is an outstanding choice for any professional workshop, combining power, efficiency, and durability in a compact and user-friendly design. Its advanced features and robust construction make it a reliable workhorse for a variety of applications.
